Seat Mount & Floor Group - S/N: 2016499707 & Above 400ZB2448 (5901275) Snapper 48" Zero-Turn Mower, 24 HP, ZTR 400Z Series

Pos		Article Number	Description
1		BS5100909SM
2		BS5402859DYP	MOUNT, SEAT STOP - RE
3		BS5407829DYP	PLATE, FLOOR - RED
4		BS5407857DYP	PLATE, SEAT MNT
5		BS5403706DYP	PLATE, ISO FLOOR MOUN
6		BS5403015AYP	SEAT PLATE, STOP
7		BS7078299SM	FEDER - SITZ
8		BS5101374YP	SAFETY WALK, FLOOR RE
9		BS703115	MUTTER
10		BS5025394SM	MUTTER, 3/8-16 SECHSK.
11		BS5025011X8SM	BOLZEN, 5/16-18 X 1" GD
12		BS703302	U-SCHEIBE, 5/16
13		BS5044617SM	SCHEIBE, 34 X 1.25 X
14		BS5023263SM	KLEMME VINYL
15		BS703463	MUTTER, GR5,1/4-20
16		BS5025013X8SM	BOLZEN, 3/8-16 X 1" GD5
17		BS5025156SM	SCHEIBE, 3/8" SAE
18		BS5025145X10YP	BOLT, 5/16-18 X 1-1/4
19		BS5025127SM	MUTTER, 5/16-18 SECHSK.
20		BS5021878YP	SPACER, .25 X .37 X .
21		BS5101333YP	SAFETY WALK, FLOOR PL
22		BS5025144X6SM
23		BS5101004SM
24		BS197546GS	MONTAGEKLOTZ
25		BS5025011X6SM	BOLZEN, 5/16-18 X 3/4"
26		BS5025013X12SM	BOLT, 3/8-16 X 1-1/2"
27		BS5103071YP	FLANGED BUSHING
28		BS5025145X6SM	BOLT, 5/16-18 X 3/4",
29		BS5025145X10YP	BOLT, 5/16-18 X 1-1/4
30		BS703164	MUTTER
31		BS1670578SM	KNOB-INT THR .312-18
32		BS1686907SM	ARMLEHNESATZ
33		BS5100652SM
34		BS5061599X1SM	SITZ SCHIENENKITT L/R
