Spare Parts Lists for Toro Roth / TORO Engine B&S Model 28N777-0174-01

Lists

pos.	decription	spare part number
1	Cylinder Assembly	496412
2	Bearing-Cylinder Note: Installation Requires Special Tools	399265
3	Seal-Oil	391086
8	Breather Assembly	495735
9	Gasket-Valve Cover	27803
10	Screw	94621
11	Tube-Breather	281246
225	Crank-Governor	495157
227	Lever Assy.-Governor	493935
230	Washer-Gov.Crank	94742
284	Screw-Sem	94073
306	Shield-Cylinder	225020
307	Screw-Cylinder Shield Mtg. Sem	94623
337	Plug-Spark	491055
383	Wrench-Spark Plug	89838
523	Cap and Dipstick Oil Filler	495230
524	Seal-Filler Tube	281370
525	Tube-Oil Filler	496113
552	Bushing-Gov. Crank	231597
562	Bolt, Governor Lever	92613
592	Nut-Hex.-10-24	231082
614	Cotter, Hair Pin	93306
634	Seal-Oil	491323
635	Elbow-Spark Plug	280872
718	Pin-Cylinder	230192
842	Seal-Oil Filler Cap	270920
847	Fill Group-Oil	496415
1019	Label Kit	496758
1058	Owner s Manual	273132

pos.	decription	spare part number
5	Head-Cylinder	495858
7	Gasket-Cylinder Head	272614
13	Screw-Cylinder Head	94728
33	Valve-Exhaust	495856
34	Valve-lntake	495857
35	Spring-Valve	262811
40	Retainer-Valve	224641
45	Tappet-Valve	262411
52	Gasket-Carb. Mounting	272569
166	Stud-Rocker Arm	94555
192	Ball & Screw-Rocker Arm	492160
238	Cap-Valve	262836
294	Screw-Set	810068
305	Screw-Hex. Washer Hd.	94786
868	Seal-Valve	494435
868	Seal-Valve	272610
871	Bushing-Guide (Intake and Exhaust)	262835
883	Gasket-Exhaust Pipe	272293
1022	Gasket-Rocker Cover	272475
1023	Cover-Rocker	224552
1026	Rod-Push (Intake) Note: 495136 Rod-Push (Exhaust)	494432
1029	Arm-Rocker	224554
1034	Rod-Push (Intake) Note: 495136 Rod-Push (Exhaust)	494432

pos.	decription	spare part number
	Gasket-Crkcse Cover, .005 Thick * Included in Gasket Set Part No. 494241.	271997
	Gasket-Crkcse Cover, .009 Thick * Included in Gasket Set Part No. 494241.	271996
15	Plug-Oil Drain	94239
16	Crankshaft	495162
18	Base-Engine	496742
20	Seal-Oil	291675
22	Screw-Base Mtg. Sem	94624
24	Key-Flywheel	222698
25	Piston Assembly (Standard)	494860
26	Ring Set (Standard)	495854
27	Lock-Piston Pin	260924
28	Pin Assembly-Piston-Standard	299691
29	Rod-Connecting	494504
	Rod-Conn. (.020 U.S.)	495490
46	Gear-Cam	496885
219	Oil Slinger	490815
243	Screen-Oil	225076
741	Gear-Timing	262932
757	Link-Counterweight	213998
758	Counterweight Assy.	399891
759	Pin Assy., Piston, Std.	298909
761	Screw-Counterweight	94593
1020	Eccentric	262243
1021	Pin-Eccentric	94160
1044	Screw-Hex. Head	94673
1045	Extension-Crankshaft	231828
1055	Tube-Oil Pump	231931
